12V Ignition Coil Fits Ford/New Holland Replaces 21A55112

Description

One New Aftermarket 12V Ignition Coil

Tech Info:
-2.4 Ohms Primary Resistance
-6.60 Kiloohms Secondary Resistance
-Amp Draw – 4.5 Amp Cold, Within 20 to 30 Seconds Drop to 4.0 Amps After Coil Is Warm
–
-For Tractors with Generator/alternator Mounted on the Right Side as Sitting in the Seat.
-For N-Series Tractors with Front Mount Distributor 1939-1950
-For Engines with Distributor Mounted Behind the Fan Blade (Clips to Top of Distributor)
-Note: Other Than the Factory Dash Mount Resistor FDS264, No Additional (External) Resistor Is Needed.
-Order ABC064 for the Mounting Gaskets

Made to Fit Ford/New Holland:
Tractor Models: 2N, 8N, 9N
Model Breaks: 2N (SN Less Than 263843 CONVERTED TO 12 VOLT SYSTEM), 8N (SN Less Than 263843 CONVERTED TO 12 VOLT SYSTEM), 9N (SN Less Than 263843 CONVERTED TO 12 VOLT SYSTEM)
Replaces Part Number(s): 21A55112, 9N12024

Models This Part Fits:

2N, 8N, 9NAdditional Information: 2.4 Ohms Primary Resistance6.60 Kiloohms Secondary ResistanceAmp Draw – 4.5 Amp Cold, Within 20 to 30 Seconds Drop to 4.0 Amps After Coil Is WarmFor Tractors with Generator/alternator Mounted on the Right Side as Sitting in the Seat.For N-Series Tractors with Front Mount Distributor 1939-1950For Engines with Distributor Mounted Behind the Fan Blade (Clips to Top of Distributor)Note: Other Than the Factory Dash Mount Resistor FDS264, No Additional (External) Resistor Is Needed.Order ABC064 for the Mounting Gaskets

Reference Numbers:

1100-0542, 21A55112, 9N-12024-12V, 9N-12024-12V-A, 9N12024, 9N12024-12V, 9N12024-12V-A, 9N12024-A, 9N1202412, 9N1202412-A, ABC119, IFD0003, NPW1100-0542, NPW1100-0542-A
